💎SQL Reloaded: Pulling the Strings of SQL Server VII (List of Values)

Introduction

    Lists are one of the basic structures in Mathematics, the term referring to an (ordered) set of elements separated by comma, space or any other delimiter (e.g. “:”, “;”). The elements of a list can be numbers, words, functions, or any other type of objects. In the world of databases, a list is typically formed out of the values of a given column or a given record, however it could span also a combination of rows and records, is such cases two delimiters being needed – one for column and one for row. From here comes probably the denomination of list of values. In a more general accept a list of values could be regarded as a delimited/concatenated subset. Such lists are formed when needed to send the data between the layers of an application or applications, this type of encoding being quite natural. In fact, also the data in a database are stored in similar tabular delimited structure, more complex though.

    An useful example in which the list of values are quite handy is the passing of multiple values within the parameter of stored procedure or function (see example). This supposes first building the list and then use the values in a dynamic build query (like in the before mentioned example) or by building a table on the fly. We can call the two operations composition, respectively decomposition of list of values.

Composition

Composition, whether on vertical or horizontal is nothing but a concatenation in which the values alternate with one or more delimiters. Let’s reconsider the concatenation based on the values of a Person.AddressType AdventureWorks table. As the logic for concatenating for one or more attributes is the same, the below example concatenates a list based on a single attribute, namely AddressTypeID in SingleList, respectively two attributes, AddressTypeID and Name.

-- concatenation of values across a table
;WITH CTE (AddressTypeID, Name, Ranking)
AS (--preparing the data
     SELECT AddressTypeID
     , Name
     , ROW_NUMBER () OVER(ORDER BY Name) Ranking
     FROM Person.AddressType
     -- WHERE ...
)
, DAT (SingleList, DoubleList, Ranking)
AS ( -- concatenating the values
     SELECT Cast(AddressTypeID as varchar(max)) SingleList
     , Cast('('+ Cast(AddressTypeID as varchar(10)) + ',''' + Name + ''')' as varchar(max)) DoubleList
     , Ranking
     FROM CTE
     WHERE Ranking = 1
     UNION ALL
     SELECT DAT.SingleList + ',' + Cast(CTE.AddressTypeID as varchar(20)) SingleList
    , Cast(DAT.DoubleList + ', ('+ Cast(CTE.AddressTypeID as varchar(10)) + ',''' + CTE.Name + ''')' as varchar(max)) DoubleList
    , CTE.Ranking
     FROM CTE
       JOIN DAT
          ON CTE.Ranking = DAT.Ranking + 1
)

-- the lists
SELECT SingleList
, DoubleList
FROM DAT
WHERE Ranking = (SELECT MAX(Ranking) FROM DAT)

 List of values - concatenation


   The second example is based on atypical delimiters, resembling to the structure built for a batch insert or table value constructor-based statement, and as we’ll see later, ideal to be used in a dynamically-built query

Decomposition

Decomposition follows the inverse path, though it’s much easier to exemplify. In fact it’s used the same technique introduced in the last example from the previous post belonging to the same cycle, Subparts of a String, in which a space was used as delimiter. Another example is the dbo.SplitList function which decomposes a string using a loop.


-- decomposition of a string to a table using CTE
CREATE FUNCTION dbo.StringToTable(
 @str varchar(500)
,@Delimiter char(1))
RETURNS @Temp TABLE (
Id int NOT NULL
,Value varchar(50))
AS
BEGIN
     ;WITH CTE (PrevString, Position, Word)
     AS (
     SELECT LTrim(RTrim( CASE
           WHEN CharIndex(@Delimiter, @str)>;0 THEN Right(@str, Len(@str)-CharIndex(@Delimiter, @str))
           ELSE ''
      END)) PrevString
     , 1 Position
     , LTrim(RTrim(CASE
           WHEN CharIndex(@Delimiter, @str)>0 THEN LEFT(@str, CharIndex(@Delimiter, @str)-1)
           ELSE @str
       END)) Word
      UNION ALL
      SELECT LTrim(RTrim(CASE
            WHEN CharIndex(@Delimiter, PrevString)>0 THEN Right(PrevString, Len(PrevString)-CharIndex(@Delimiter, PrevString))
             ELSE ''
       END)) PrevString
      , Position + 1 Position
      , LTrim(RTrim(CASE
           WHEN CharIndex(@Delimiter, PrevString)>0 THEN LEFT(PrevString, CharIndex(@Delimiter, PrevString)-1)
          ELSE PrevString
      END)) Word      FROM CTE
     WHERE Len(PrevString)>0
    )
     INSERT @Temp(Id, Value)
     SELECT Position
     , Word      FROM CTE
     OPTION (maxrecursion 100)
     RETURN
END

Here are two examples based on the single list created above and another one based on alphabet:


-- decomposing a list
SELECT Id
, value
FROM dbo.StringToTable('6,1,2,3,4,5', ',')


-- decomposing the "alphabet"
SELECT Id
, value
FROM dbo.StringToTable('a,b,c,d,e,f,g,h,i,j,k,l,m,n,o,p,q,r,s,t,u,v,w,x,y,z', ',')

List of values - simple decomposition

List of values - alphabet decomposition

Even if the function deals only with a delimiter, it could be used to decompose lists involving multiple delimiters, as long the list is adequately built:


-- decomposing double list
SELECT Id
, value
, Left(value, CHARINDEX(',', value)-1) LeftValue
, Right(value, len(value)-CHARINDEX(',', value)) RightValue
FROM dbo.StringToTable('6,Archive;1,Billing;2,Home;3,Main Office;4,Primary;5,Shipping', ';')

List of values - double decomposition

 The tables built thus from list of values can be further used in queries when needed to create a table on the fly. It would be interesting maybe to show that the composition and decomposition are inverse functions, however that’s out of scope, at least for current set of posts.
